Hunter 27

Rig Specifications

These are the specifications provided by the designers, but even from the factory, these boats may not be identical. The reason for this is that the sail industry often contracts manufacturing to different sources in order to achieve economies of scale. What this means is – your Hunter 27 may be more unique than you initially thought.

It’s important to note that boats are also frequently customized, so if you suspect that work has been done on yours, it’s best to take your own measurements. When ordering a sail, we will advise you if using the manufacturer’s specifications is appropriate, or if we require you to complete our own measurement forms.

I: 37.67 ft / 11.48 m

J: 11.25 ft / 3.43 m

P: 32.33 ft / 9.85 m

E: 9.92 ft / 3.02 m

Performance and Handling

The Hunter 27 sailboat is a great choice for experienced and novice sailors alike due to its comfortable and easy-to-handle sail plan. With a sail plan that enhances the sailing experience, the Hunter 27 sailboat is a versatile vessel that can accommodate sailors of all levels. The Hunter 27 sail plan uses a fractional rig with a deck-stepped mast and a single-spreader rig, which provides good balance and control. The mainsail is a full-batten design with a lazy jack system, which makes it easy to handle and stow. The jib is a roller furling design, which allows for quick and easy adjustments to the sail area.

The Hunter 27 is also equipped with a reliable and efficient outboard engine, which provides good power and maneuverability in tight spaces. The fuel tank has a capacity of 6 gallons, which allows for several hours of motoring at cruising speed. The boat also has a freshwater tank with a capacity of 20 gallons, which provides enough water for a weekend or longer trip.

Design and Construction

The Hunter 27 is a modern sailboat with a sleek and stylish design that combines comfort and performance. It has a length overall (LOA) of 27 feet and a beam of 9 feet, 11 inches, which provides a spacious cockpit and cabin. The sail area is 321 square feet, which allows for good speed and maneuverability in most wind conditions.

The hull is made of hand-laminated fiberglass with a balsa core, which provides a strong and durable structure that is also lightweight. The standard keel is a cast iron fin with an optional shoal draft keel or a wing keel. These variations slightly change the handling depending on what kind of sailing you plan on doing. The rudder is a balanced spade type, which provides good control and responsiveness.

Comfort and Amenities

The Hunter 27 is a comfortable and well-appointed sailboat that provides all the amenities and features that a sailor would need for a pleasant and enjoyable trip. The cockpit has comfortable seating and a folding table, which allows for outdoor dining and relaxation. The cabin has a V-berth and a double berth, which provides comfortable sleeping quarters for up to four people. The head is located aft of the V-berth and includes a sink, a manual toilet, and a shower.

The galley is located on the starboard side of the cabin and includes a sink, a two-burner stove, and a built-in icebox. The interior is finished in a high-quality teak veneer, which provides a warm and inviting atmosphere. The boat also has several storage compartments and lockers, which provide ample space for personal belongings and equipment.

Overview

Overall, the Hunter 27 sailboat is a well-designed and well-built cruiser that provides good performance, comfort, and amenities for a variety of sailing conditions. It is a popular choice for sailors who want a versatile and easy-to-handle sailboat that can accommodate a small crew and provide a comfortable and enjoyable sailing experience. If you are looking for a sailboat in this size range, the Hunter 27 is definitely worth considering.
